TR3050

FEATURES:

20mA version:

• Rectangular LED RF performance
  • 450 & 460 nm: 36 mW min.
• Epoxy die attach
• Low forward voltage: 2.95 V typical at 20 mA
• 1000-V ESD threshold rating
• InGaN junction on thermally conductive SiC substrate

50mA version:

• Rectangular LED R_F performance
  • 450 & 460 nm: 76 mW min.
• Epoxy die attach
• Low forward voltage: 3.2 V typical at 50 mA
• 1000-V ESD threshold rating
• InGaN junction on thermally conductive SiC substrate
